Main Application
• Entry Borad For PCB Drilling Processes.Product Specification
| Item | Unit | Value |
| Thickness | mm | 0.15、0.18、0.2(±0.02mm) built-to-order |
|
Size |
mm | built -to-order(±2mm)) |
|
Tensile Strength |
N/mm² | >130 |
| Yield Strength |
N/mm² | >150 |
| Elongation | % | >1.0 |
| Color | Sliver | |
| Storage | Keep in dry, cool place and avoid direct sunlight. 20°C and 50 -60% relative humidity. |
|
Chemical Composition(%)
| Si | Fe | Cu | Mn | Zn |
Other |
Al | |
| Each | TOT | ||||||
| Si+Fe1.0以下 | 0.05~0.2 | <0.05 | <0.1 | <0.05 | <0.15 | >99.0 | |
