Main Application
• Inner layer application using low profile foils.• Suitable for fine patterns.
Product Specification
| Item | Unit | Value | Test Method | ||||
| Nominal Thickness | µm | 12 | 18 | 35 | 70 | - | |
| oz | 1/3 | 1/2 | 1 | 2 | |||
|
Thickness by weight |
g/m² | 107±5% | 153±5% | 285±5% | 585±5% | IPC-TM650 | |
| Purity | % | ≧99.8 | ≧99.8 | ≧99.8 | ≧99.8 | IPC-TM650 | |
| Tensile Strength | at RT | kg/mm² | ≧21 | ≧21 | ≧28 | ≧28 | IPC-TM-650 |
| at 180℃ | kg/mm² | ≧15 | ≧15 | ≧15 | ≧15 | ||
| Elongation | at RT | % | ≧3 | ≧4 | ≧5 | ≧5 | IPC-TM-650 |
| at 180℃ | % | ≧2 | ≧3 | ≧3 | ≧3 | ||
| Ronghness (Ra) | Laminate | µm | ≦5.0 | ≦5.0 | ≦5.0 | ≦5.0 | IPC-TM-650 |
| Resist | µm | ≦6.0 | ≦6.0 | ≦8.0 | ≦10.0 | IPC-TM-650 | |
| Peel Strength (FR-4) | kg/cm | ≧0.8 | ≧0.8 | ≧0.8 | ≧0.9 | IPC-TM-650 | |
| lb/in | ≧4.5 | ≧4.5 | ≧4.5 | ≧5.0 | |||
